Technical specification
Charging Mode (Buck)
Input Main Voltage: DC750V(600~900V)
Input Power Source: Catenary
Rated Output Voltage: DC502V (439~573V)
Charging Battery Current: 87A (from Battery)
Discharging Mode (BOOST)
Input Main Voltage: DC502V(439~573V)
Input Power Source: Battery
Rated Output Voltage: DC750V (600~900V)
Continuous Discharging Current: 288A
Max Discharging Current: 500A(＜10S)
Others
Efficiency: ≥95%
Cooling Mode: Forced Air Cooling
Dimension: 1369*800*600
Weight: ≤350kg
Application
Electric Locomotive
Austria
Installed quantity
1
