Technical specification
Main & Auxiliary Generator Excitation Module
Input Voltage: 3P 73~220V(from Alternator)
Input Current: Max. Current for Each Phase 160A
Output Voltage: Main Generator Excitation DC32V ,
Auxiliary Generator Excitation DC30V
Output Current: Main Generator Excitation 140A,
Auxiliary Generator Excitation 105A
Battery Charger Module
Input Voltage: 3P 146~440V
Rated Output Power: 26kW
Output Voltage: DC74V(70.5~78.5V)
Air Conditioner Compressor Inverter Module
Input Voltage: 3P 146~440V(from Alternator)
Output Voltage: 3P 135V±5%
Output Current: 110A
Cooling fan Inverter Module
Input Voltage: 3P 146~440V(from Alternator)
Output Voltage: 3P 432V±5%
Output Current: 47A
Others
Cooling Mode: Forced Air Cooling
Dimension: 630*1350*2050
Weight: 1000kg
Input-Output Galvanic Isolation with MF Transformer
Application
Shunting
Locomotive
MTR
Installed quantity
25
